35 Man Throw Over Board Liferaft marine liferaft for sale
35 Man Throw Over Board Liferaft
Type: 30\35 Man Throw Over Board Life raft.
Suitable for installing in the vessels sailing on international voyages.
It meets the China MSA-“ Regulations for the Statutory Surveys of Ships and offshore Installations—Technical Regulations for the Statutory Surveys of Sea-going Ships Engaged inDomestic Voyages”2004,and it′s 2008 Amendments,Part4, Ch.3.and SOLAS(74/96),
LSA,MSC.81(70), MSC.226(82), MSC.218(82), MSC.293(87),ISO15738(2002).
Max. Storage Height: 18~36m.
Equipment Outfit: SOLAS A \B PACK.
Certificates:CCS,GL.
Type | 30Man | 35Man | |
Shape | Rectangular octagon
| ||
Capacity (Persons) | 30 | 35 | |
Dimension(L×W×H) | 5384×3414×1700 | 5899×3568×1750 | |
Cylinder | 9L×2 | 12L×2 | |
Container dimension (mm) | SOLAS A PACK (a×b) | 1700×795 | |
SOLAS B PACK (a×b) | 1470×735 | ||
Packaging dimension (mm) | SOLAS A PACK (c×d×e) | 1780×855×880 | |
SOLAS B PACK (c×d×e) | 1540×805×790 | ||
Required bollard pull (KN) | For 2knot speed | 1.10 | 1.30 |
For 3knot speed | 2.10 | 2.40 | |
Weight (kg) | ≤205 | ≤230 |
